Tehnical Data

External diameter of the pipe: max 38mm
Maximum torque: 914N/m
Capacity with FE of 42 from N/mm2: 33.4×3.38 mm
Capacity with FE of 35 from N/mm2: 38×2 mm
AISI 304/316 capacity of 65 N/mm2: 33.4×1.5 mm
Maximum radius: 160mm
Maximum bending angle: 180°
Curvation direction: right and left
Voltage: 220V
Maximum installed power: 0.52kW
Weight: 33Kg
Dimensions: 478x310x268 mm
Operating temperature: from 0 to 50 °C
