Tehnical Data

External diameter of the pipe: max 50mm
Maximum torque: 2400N/m
Capacity with FE of 42 from N/mm2: 48×3.5 mm
Capacity with FE of 35 from N/mm2: 48×4 mm
AISI 304/316 capacity of 65 N/mm2: 48×2 mm
Maximum radius: 250mm
Head height: 188mm
Head fusion: 285mm
Maximum bending angle: 180°
Curvation direction: right and left
Voltage: 380V
Maximum installed power: 1.1kW
Weight: 110Kg
Dimensions: 700x970x440 mm
Operating temperature: from 0 to 50 °C
